Ref : 50303

4-1/2"-5" (114 mm-127 mm) Dia. Vertical Depressed Center Wheel Grinder

1.2 hp, 12,000 RPM, Side Exhaust, 5/8"-11 Spindle Thread

$1,463.00 Tax Excl.
Share

  • Depressed Center Wheel Grinder, for fast weld and stock removal, rust and scale removal, heavy deburring.

  • 4-1/2" - 5" Diameter, Vertical, 1.2 hp, Side Exhaust, 12,000 RPM.

  • Accepts optional Type 27 Depressed Center Wheel in diameters of 4-1/2" and 5", with 7/8" center hole (wheel width of 1/8" to 1/4"). Powerful air motor is governor-controlled to maintain RPM under heavy load.

  • Gearless for reduced maintenance and downtime. Safety-lock throttle lever prevents accidental startup. Side handle increases safety and reduces hand fatigue.

  • Guard and wheel flange set included.

Length (mm)
203 mm
Width (mm)
203 mm
Air Inlet Thread
Exhaust Type
Height (in)
7 in
Height (mm)
168 mm
Hose I.D.
hp
1.2 hp
Length (in)
8 in
Max. RPM
12000
Vacuum Type
Width (in)
8 in
Tool Style
Vertical
Weight (kg)
2.7 kg
Weight (lb)
5.95 lb
Current Manual (Parts Page) PD04.48
Tune-Up Kit Page 96041
Literature 00001676
